Specifications |
| Seat Width |
|
|
|
| Weight Capacity |
|
250 Pounds. |
7.2% Wheelchairs have 250 pounds. |
| Seat Depth |
|
|
|
| Back Height |
|
|
|
| Arm Style |
|
Swing Away Tubular Style Arms Are Available As An Option. Arm Accessories Include: Removable Sideguards, Removable Cloth Sideguards With Rigidizer, Fixed Aluminum Or Carbon Fiber Sideguards, Folding Aluminum Or Removable Sideguards With Fender. |
|
| Camber |
|
Center Of Gravity Adjustment Is 4.25". Camber Choice Of 0,3,6 Or 9 Degrees. |
|
| Footrest |
|
One Piece Tubular Footrest Or An Adjustable Angle Footplate Are Available As Standard. Footplate Covers Made Of Carbon Fiber Or Plastic Are Available As An Option For The Tubular Footrest. |
|
| Frame |
|
Custom Built Rigid Ultra-lightweight Open Frame Or Cantilever Design. Available In 5 Front Frame Angles: 70,75,80,85 Or 90 Degrees. New Ergo Seat Option Provides Optimum Positioning, Good Pressure Distribution And Better Propulsion. See Additional Images Or On-line Brochure For More Details. |
|
| Back Angle |
|
Back Angle Is Adjustable On Folding Back With 5 Settings And Fixed On Fixed Back. Please See Order Form For Details. |
|
| Wheels |
|
High Performance Radial Wheels With Double Wall Rims And High Flange Hubs Equipped With High Pressure Clincher Tires And Anodized Aluminum Push Rims Are Standard. Optional Spinergy Spox Wheels With Black Or Yellow Spokes Are Available. Other Tire Available Include Pneumatic 1-3/8" Treaded As A No Charge Option And Knobby, Kik, Kenda Or Flat Free Inserts Are Optional. |
|
| Frame Tubing |
|
6061 T6 Aluminum In 1-1/8" Tubing Size. |
|
| Seat Height |
|
Front Seat To Floor Height: 16"-21" Rear Seat To Floor Height: 14"-21" |
|
| Wheel and Caster Size |
|
22", 24" Or 25" Available As Standard. 26" Available As Option. Front Semi-pnuematic Casters 4" Or 5", 3" Micro Are Standard. Softroll Aluminum Casters 4" Or 5" Are Optional. |
|
| Back Options |
|
Folding Back Is Standard And Fixed Back Is Optional. Upholstery Is Adjustable Tension W/straps As Standard And Fold- Over Style As Optional. Additional Options Include Bolt-on Or Integral Push Handles. |
|
| Caster Suspension Options |
|
Frog Leg Front Suspension Forks Are Available As An Option. |
|
| Foot Space Width |
|
Footspace Width For Tapered Front End Is Seat Width Minus 6" And For V Style Is Seat Width Minus 5". For Seat Widths Of 12", 13" Or 14" The Footrest Space Is 8". |
|
|
|
|
